Looks like every manufacturer will be enhancing their boards with USB 3 and SATA 3 on their boards. Just after we saw the new ASRock P55 Deluxe3, ASRock has the X58 Deluxe3 which is based on the INTEL X58 chipset for LGA1366 processor.

Below is the specification of the X58 Deluxe3

  1. Intel® Socket 1366 Core™ i7 Processor Extreme Edition / Core™ i7 Processor Supports Intel® Dynamic Speed Technology
  2. System Bus up to 6400 MT/s; Intel® QuickPath Interconnect
  3. ASRock DuraCap (2.5 x longer life time), 100% Japan-made high-quality Conductive Polymer Capacitors
  4. Intel® X58 + ICH10R Chipsets
  5. Supports Triple Channel DDR3 2000(OC)/1866(OC)/1600(OC)/1333(OC)/1066 (6 x DIMM slots) non-ECC, un-buffered memory, Max. capacity up to 24GB
  • Supports DDR3 ECC, un-buffered memory with Intel® Workstation 1S Xeon® processors 3500 series
  • Supports Intel® Extreme Memory Profile (XMP)
  • 4 x PCI Express 2.0 x16 slots (blue @ x8 / x16 mode, orange @ x8 / N/A mode) (Double-wide slot spacing between each PCI-E slot)
  • Supports ATI™ Quad CrossFireX™, 3-Way CrossFireX™ and CrossFireX™
  • Supports NVIDIA® Quad SLI™, 3-Way SLI™ and SLI™
  • PCIE x1 Gigabit LAN 10/100/1000 Mb/s
  • 6 x SATAII 3.0 Gb/s connectors, support RAID (RAID 0, RAID 1, RAID10, RAID 5 and Intel® Matrix Storage), NCQ, AHCI and Hot Plug functions
  • 1 x Powered eSATAII/USB Connector
  • Supports 2 x IEEE1394 ports (one port on back panel, one header on board)
  • 7.1 CH HD Audio with Content Protection, supports DAC with 110dB dynamic range (ALC890 Audio Codec)
  • Premium Blu-ray audio support
  • Compatible with Windows® 7
  • Supports ASRock Instant Boot, Instant Flash, OC Tuner, IES, OC DNA
  • Free Bundle: CyberLink DVD Suite – OEM and Trial; Creative Sound Blaster X-Fi MB – Trial
  • Free Bundle: 2 x ASRock XFire_Bridge_3S Cards, 1 x ASRock SLI_Bridge_3S Card, 1 x ASRock 3-Way SLI Bridge Card, 1 x ASRock SATA3 Card, 1 x ASRock USB 3.0 Card
  • I/O Panel : 1 x Coaxial SPDIF Out Port, 1 x Optical SPDIF Out Port, 6 x Ready-to-Use USB 2.0 Ports, 1 x Powered eSATAII/USB Connector, 1 x RJ-45 LAN Port with LED, 1 x IEEE 1394 Port
This model may not be sold worldwide. Please contact your local dealer for the availability of this model in your region.
