- Intel® Socket 1366 Core™ i7 Processor Extreme Edition / Core™ i7 Processor Supports Intel® Dynamic Speed Technology
- System Bus up to 6400 MT/s; Intel® QuickPath Interconnect
- ASRock DuraCap (2.5 x longer life time), 100% Japan-made high-quality Conductive Polymer Capacitors
- Intel® X58 + ICH10R Chipsets
- Supports Triple Channel DDR3 2000(OC)/1866(OC)/1600(OC)/1333(OC)/1066 (6 x DIMM slots) non-ECC, un-buffered memory, Max. capacity up to 24GB
- Supports DDR3 ECC, un-buffered memory with Intel® Workstation 1S Xeon® processors 3500 series
- Supports Intel® Extreme Memory Profile (XMP)
- 4 x PCI Express 2.0 x16 slots (blue @ x8 / x16 mode, orange @ x8 / N/A mode) (Double-wide slot spacing between each PCI-E slot)
- Supports ATI™ Quad CrossFireX™, 3-Way CrossFireX™ and CrossFireX™
- Supports NVIDIA® Quad SLI™, 3-Way SLI™ and SLI™
- PCIE x1 Gigabit LAN 10/100/1000 Mb/s
- 6 x SATAII 3.0 Gb/s connectors, support RAID (RAID 0, RAID 1, RAID10, RAID 5 and Intel® Matrix Storage), NCQ, AHCI and Hot Plug functions
- 1 x Powered eSATAII/USB Connector
- Supports 2 x IEEE1394 ports (one port on back panel, one header on board)
- 7.1 CH HD Audio with Content Protection, supports DAC with 110dB dynamic range (ALC890 Audio Codec)
- Premium Blu-ray audio support
- Compatible with Windows® 7
- Supports ASRock Instant Boot, Instant Flash, OC Tuner, IES, OC DNA
- Free Bundle: CyberLink DVD Suite – OEM and Trial; Creative Sound Blaster X-Fi MB – Trial
- Free Bundle: 2 x ASRock XFire_Bridge_3S Cards, 1 x ASRock SLI_Bridge_3S Card, 1 x ASRock 3-Way SLI Bridge Card, 1 x ASRock SATA3 Card, 1 x ASRock USB 3.0 Card
- I/O Panel : 1 x Coaxial SPDIF Out Port, 1 x Optical SPDIF Out Port, 6 x Ready-to-Use USB 2.0 Ports, 1 x Powered eSATAII/USB Connector, 1 x RJ-45 LAN Port with LED, 1 x IEEE 1394 Port
This model may not be sold worldwide. Please contact your local dealer for the availability of this model in your region.
|
