ASRock releases pictures of 4 models of Intel X79 boards – X79 Extreme4 M, X79 Extreme4, X79 Extreme7 and X79 Extreme9; X79 Extreme4 M – the first mATX X79 board
ASRock X79 Extreme4 M
So far we have seen a number of ATX boards. This is probably the first mATX board that we come across.
The ASRock X79 Extreme4-M looks very elegant in that Gold/Black colour scheme. With 3 full length PCIe 3.0 slots and 1 PCI slot on board, the PCIe slots are capable of supporting either CrossFire X or SLI.
In terms of expansion, there are only 4 memory slots, 2 on each side of the socket LGA2011. DDR3-2400+ (OC) is supported as indicated on the mainboard.
On the board, we can also see the power on/off, reset, debug led. There are 6 SATA connectors on the front. The board also supports 1394a, USB 3.0.
On the back of the mainboard, we can see the PS/2 keyboard & mouse connectors, S/PDIF optical and digital out, USB 3.0, eSATA, GbE and audio ports.
The chipset is attached with a heatsink / fan powered by X-FAN.
More on next page
